PET Water Bottle Date Laser Printer


Product model:MH C0-30/ MH CO-30i

Product introductionFor printing date batch expiry lot number on PET plastic bottles , Minghong manufacturer builds two different wavelength CO2 laser printers according to the user's product needs and budget. One of the two wavelength CO2 lasers is wavelength 10.6um CO2 laser , the other one is 9.3um CO2 laser. Both of these two wavelength CO2 laser printers can print clear and permanent traceability messages on the PET bottles

Technical support:

Application field:beverage industry for water bottles , beverage bottle date batch , expiry , lot number printing

Product parameter
  1. Product name

  2. Model number

  3. laser power

  4. Laser brand

  5. Laser type

  6. wavelength

  7. Laser repetition rate

  8. Marking range

  9. Minimum font size

  10. Minimum line width

  11. Repetition accuracy

  12. Machine power

  13. Positioning mode

  14. Control system

  15. Operation language

  16. Power supply

  17. Cooling mode

  18. Font format

  19. Coding content

  20. Suitable material

  21. Machine size

  22. Machine structure

  23. Machine weight

  24. Package size

  1. Flying 30W CO2 laser coding machine

  2. MH CO-30/MH CO-30i

  3. 30W

  4. David/ Chenruida/Synrad/Coherent  for option

  5. Metal RF tube CO2 source , steand and reliable

  6. 10.6um.10.2um ,9.3um

  7. 20KHZ-100KHZ

  8. 110*110m

  9. 0.15mm

  10. 0.01mm

  11. ±0.002

  12. ≤800W

  13. Red light focusing

  14. All-in-one touch screen

  15. Chinese, English, Spanish, Turkish, Arabic, Thai

  16. AC110V-220 50HZ,

  17. Air cooling

  18. TTF font

  19. Date, expiration date, bar code, QR code, LOGO, vector, text, number

  20. PET water bottle, plastic bag, plastic film, paper box, glass bottle, plastic pipe, LED belt, drip belt pipe

  21. 60*90*150cm

  22. Aluminum profile

  23. 55KG

  24. 138*64*39cm ;Gross weight : 77KG

Product details

DESCRIPTION

Minghong  CO series fly CO2 laser printer  is wildly applicable in all kinds of industries such as food, beverage, cosmetic, pharmacy, furniture, electronic, pipes et., for placing messages which include date, batch, expiry, 2d code, barcode, series number, logo, text et. It  is flexible and  suitable for various of material such as Plastic( PET BOTTLE, Plastic bag, PVC pipes etc., ), leather, glass, paper, wood, some metal product which surface is painting etc., and other non-metalic product, which is an ideal traceability system for industries.





FEATURES

                                                    1. Small in Size, it can be fit for narraow working enviroment , laser machine main body can be fix on the integrated packaging machine like vertical packing machines

                                                    2. Non need of inks consumables, non need of daily maintenace , low cost for using

                                                    3. Industrial touch screen system, easy to operate, language support English , Chinsee, Arabic , Russia , VIetnamese , Portuguese, Greece, French, Germany, SPanish

                                                    4. Full aluminum structure, strong and steady

                                                    5. Permanent marking, non- erased , effective for counterfeiting

                                                    6. High efficient, steady &reliable

                                                     7.  Applicable for various of industries as beverage , food , pharmacy, cosmetic, pipe, led lighting ....
